LZ Series Split Type Chiller
The LZ series split type chiller consists of an indoor unit and an outdoor unit. The outdoor unit consists of a refrigeration compressor, a hot air exhaust fan, and a condenser, which discharge all the heat generated by refrigeration to the outside. At the same time, the main noise source is also located outdoors. The indoor unit consists of a water pump, water tank, and evaporator, which generate no heat and have very low noise.
Split unit is an environmentally friendly chiller suitable for laboratory with high requirements for environmental comfort and noise. Large split units are also friendly matching with industrial equipment. This series of chillers is used in X-ray diffraction, X-ray fluorescence spectrometer, and plasma emission spectroscopy(ICP) etc. Also good results have been achieved in supporting large-scale laboratory equipment such as industrial equipment with high heat generation, like vacuum coating machines, ion coating machines, vacuum furnaces, and industrial furnaces.
1. Optional PID intelligent temperature controller, with a temperature control accuracy of 0.1 ℃ -0.5 ℃;
2. Low indoor vibration, low noise, and no heat dissipation;
3. High water pressure, suitable for customers with high water pressure requirements;
4. It can be connected to an external sound and light alarm, making the equipment operate more safely;
5. High and low pressure monitoring of the refrigeration system, facilitating users to understand the operation of the system;
6. Comes with compressor overheat protection, overcurrent protection, high and low pressure protection, and phase sequence/phase loss protection.
Analytical instrument field: X-ray diffractometer, X-ray fluorescence spectrometer, electromagnet, nuclear magnetic resonance instrument (MRI);
Vacuum equipment field: vacuum coating machines (including vacuum ion evaporation/magnetron sputtering/MBE molecular beam epitaxy/PLD laser sputtering deposition), vacuum furnaces, plasma etching machines, vacuum pumps (molecular pumps/diffusion pumps/rotary vane pumps/Roots pumps/dry pumps).
